What is ASTM A967? A Practical Guide for Manufacturers
ASTM A967: Standards for Stainless Steel Passivation
Stainless steel is one of the most common materials in the world. It’s found in homes, it’s used in workplaces, and it supports major infrastructure all over the world. But allowing corroded or rusted stainless steel parts into your assembly line can be catastrophic. Even the smallest compromised part can jeopardize construction timelines, fail quality control audits, and waste manufacturers’ time and money.
In order to avoid these setbacks and failures, there are standard industry specifications for the chemical passivation treatment of stainless steel parts. This standard is referred to as ASTM A967.
The goal of the ASTM A967 standard is to provide a standardized specification for passivating stainless steel parts. This process focuses on removing free iron and surface contaminants to optimize corrosion resistance.
ASTM A967 is the go-to commercial standard used by manufacturers in industries like aerospace, medical devices, automotive, and food processing to ensure their stainless steel components are sanitary and built to last. It provides guidelines on setting up your passivation process to meet the correct specifications, spelling out particular standards for bases and alloys, correct bath temperatures, correct chemical concentration, and the right amount of exposure time.
The ASTM A967 parameters provide the keys to a successful passivation process and methods to test if you’ve passivated your parts successfully. Tests like copper sulfate, water immersion, salt spray, and high humidity help to gauge passivation success.
We’ll break down the main steps manufacturers take using the ASTM A967 process.
Step 1: Pre-Cleaning
Pre-cleaning is the most critical step and sets your passivation process up for success. Without a clean part, the rest of the steps won’t matter. You cannot properly passivate a dirty part, and any fluids, grease, or contaminants will prevent the acid from reaching the surface of the stainless steel. The contaminants will act as a barrier, leaving portions of the part unpassivated and susceptible to rust.
Step 2: Choosing Your Passivation Chemistry
While ASTM A967 gives manufacturers two options for the passivation bath—either nitric acid or citric acid—citric acid is often the recommended method today. Nitric acid can be extremely dangerous, producing toxic fumes and posing a burn hazard. It was the industry standard for many years, but recent upgrades to the process have paved the way for a citric acid alternative.
Citric acid is a more modern and safer option for passivation. It’s organic but highly effective at dissolving free iron. The key to proper citric passivation is correct bath temperatures and immersion times, outlined in ASTM A967.
Step 3: The Passivation Bath
Once the part is clean and you have chosen your chemistry, submerge the stainless steel part in a chemistry bath. ASTM A967 provides specific details for time, temperature, and concentration based on which bath chemistry you selected. A bath that is too cold, too hot, or too diluted has the potential to fail and leave excess free iron. This can cause damage to the surface of your part.
Step 4: Rinsing
Once the part is removed from the acid bath, manufacturers must stop the chemical reaction. This is achieved through rinsing. Use a clean water bath, such as DI or RO water, to thoroughly rinse the part. Getting rid of any and all residual acid is imperative.
Step 5: Verification Testing
To ensure that the passivation process was successful, manufacturers must follow ASTM A967 guidelines to test the results. Several testing methods include:
- The Water Immersion Test: Submerging parts to check for rusting.
- The High Humidity Test: Exposing parts to moisture.
- The Salt Spray Test: A common accelerated corrosion test.
- The Copper Sulfate Test: A test that turns pink if free iron is still present.
What are the benefits of standardization in the parts cleaning industry?
The ASTM A967 specifications were the answer to a growing demand for a standardized passivation procedure. With the evolution of parts cleaning and changes in the industry over time, manufacturers were looking for a way to get on the same page.
ASTM A967 gives parts cleaners a consistent process to follow and guidelines to ensure that passivation is done correctly. With ASTM A967, the work to crack the code on passivation is already done. Manufacturers don’t have to spend time and money on research and development to figure out the best process. They just need to follow the specifications.
————-
If you’re looking for more information about the ASTM A967 standards or citric passivation, our team at JAYCO Chemical Solutions can help. Explore our products or schedule a consultation today.
